Precision Fiber Laser

Pulsed mode for fine detail up to 8 mm

The NEONA precision fiber laser in its enclosure, control console on the left and extraction behind

Precision Laser Cutting of Fine Detail

The NEON.BG precision fiber laser is built by NEONA and runs at 2000 W from an IPG source, with a working format of 2500 × 1250 mm. Its pulsed mode cuts fine detail and S-curves without deforming the material — work the high-power laser cannot take on.

A linear drive system keeps the motion precise and smooth. Besides cutting, the machine engraves and marks metal, including laser marking during the cut itself to record a part's position and orientation.

The cutting head producing a dense array of narrow parallel slots separated by thin webs

Key capabilities

  • Manufacturer: NEONA
  • Working format: 2500 × 1250 mm
  • Power: 2000 W, IPG source
  • Pulsed mode for fine detail and S-curves without deformation
  • Steel: up to 8 mm
  • Aluminium: up to 6 mm
  • Stainless steel: up to 4 mm
  • Cutting, engraving and marking of metal
